Product Summary

The LTV-817-A is a high density mounting type photocoupler. The applications of the LTV-817-A include Computer terminals, System appliances, measuring instruments, Registers, copiers, automatic vending machines, Electric home appliances such as fan heaters, etc.

Parametrics

LTV-817-A absolute maximum ratings: (1)Forward Current: 50 mA; (2)Reverse Voltage: 6 V; (3)Power Dissipation: 70 mW; (4)Collector-Emitter Voltage: 35 V; (5)Emitter-Collector Voltage: 6 V; (6)Collector Current: 50 mA; (7)Collector Power Dissipation: 150 mW; (8)Total Power Dissipation: 200 mW; (9)Operating Temperature: -30 to +100 ℃; (10)Storage Temperature: -55 to +125 ℃.

Features

LTV-817-A features: (1)Current transfer ratio (CTR : MIN. 50% at IF=5mA, VCE=5V); (2)High input-output isolation voltage: (VISO : 5,000Vrms); (3)Compact dual-in-line package: LTV-817 : 1-channel type, LTV-827 : 2-channel type, LTV-847 : 4-channel type; (4)UL approved (No. E113898); (5)TUV approved (No. R9653630); (6)CSA approved (No. CA91533-1); (7)FIMKO approved (No. 202634); (8)NEMKO approved (No. P98101945).

Diagrams

LTV-817-A package dimensions
