Product Summary
The MAX489ECSD is low-power transceiver for RS-485 and RS-422 communications in harsh environments. The driver output and receiver input is protected against ±15kV electro-static discharge (ESD) shocks, without latchup. The part contains one driver and one receiver.
Parametrics
MAX489ECSD absolute maximum ratings: (1)Supply Voltage (VCC): 12V; (2)Control Input Voltage: -0.5V to (VCC + 0.5V); (3)Driver Input Voltage (DI): -0.5V to (VCC + 0.5V); (4)Driver Output Voltage (Y, Z; A, B): -8V to +12.5V; (5)Receiver Input Voltage (A, B): -8V to +12.5V; (6)Receiver Output Voltage (RO): -0.5V to (VCC + 0.5V); (7)8-Pin Plastic DIP (derate 9.09mW/℃ above +70℃): 727mW; (8)14-Pin Plastic DIP (derate 10.00mW/℃ above +70℃): 800mW; (9)8-Pin SO (derate 5.88mW/℃ above +70℃): 471mW; (10)14-Pin SO (derate 8.33mW/℃ above +70℃): 667mW; (11)Operating Temperature Range: -40 to +85℃; (12)Storage Temperature Range: -65 to +160℃; (13)Lead Temperature (soldering, 10sec): +300℃.
Features
MAX489ECSD features: (1)For Fault-Tolerant Applications; (2)For Space-Constrained Applications; (3)For Multiple Transceiver Applications; (4)For Fail-Safe Applications; (5)For Low-Voltage Applications.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MAX489ECSD |
Maxim Integrated Products |
RS-422/RS-485 Interface IC |
Data Sheet |
Negotiable |
|
||||||||||||
|
MAX489ECSD+ |
Maxim Integrated Products |
RS-422/RS-485 Interface IC RS-485/RS-422 Transceiver |
Data Sheet |
|
|
||||||||||||
|
MAX489ECSD+T |
Maxim Integrated Products |
RS-422/RS-485 Interface IC RS-485/RS-422 Transceiver |
Data Sheet |
|
|
||||||||||||
 |
MAX489ECSD-T |
Maxim Integrated Products |
RS-422/RS-485 Interface IC |
Data Sheet |
Negotiable |
|
||||||||||||
