Product Summary

The DTC123JUAT106 is a 100mA/50V digital transistor with built-in resistors.

Parametrics

DTC123JUAT106 absolute maximum ratings: (1)Supply voltage, Vcc: 50V; (2)Input voltage, VIN: -5 to +12V; (3)Ouput current, IO: 100mA; (4)IC(Max.): 100A; (5)Power dissipation, Pd: 150mW; (6)Junction temperature, Tj: 150℃; (7)Storage temperature, Tstg: -55 to +150℃.

Features

DTC123JUAT106 features: (1)Built-in bias resistors enable the configuration of an inverter circuit without connecting external input resistors; (2)The bias resistors consist of thin film resistors with complete isolation to allow negative biasing of the input; (3)They also have the advantage of almost completely eliminating parasitic effects; (4)Only the on / off conditions need to be set for operation, making device design easy.

Diagrams

DTC123JUAT106 dimension

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
DTC123JUAT106
DTC123JUAT106
ROHM Semiconductor
Transistors Switching (Resistor Biased) NPN 50V 100MA SOT-323
Data Sheet
0-1: $0.26
1-25: $0.14
25-100: $0.09
100-500: $0.05
