LT1961EMS8E#PBF

1.5A, 1.25MHz, monolithic boost, switching regulator, 8MSOP, 0.2Ω

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.80~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.80~1.00

PartNumber:: LT1961EMS8E#PBF

Brand:: Linear Technology - Linear | Pack: MSOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Joy's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-29

From Other Seller

Part Number:LT1961EMS8E#PBF
US $0.80 - 1.00
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
IRF3205

US $0.80 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LT1961EMS8E#PBF is a 1.25MHz monolithic boost switching regulator. A high efficiency 1.5A, 0.2Ω switch is included on the die together with all the control circuitry required to complete a high frequency, current-mode switching regulator. Current-mode control of the LT1961EMS8E#PBF provides fast transient response and excellent loop stability. New design techniques achieve high efficiency at high switching frequencies over a wide operating voltage range.

Parametrics

LT1961EMS8E#PBF absolute maximum ratings: (1)Input Voltage: 25V; (2)Switch Voltage: 35V; (3)SHDN Pin: 25V; (4)FB Pin Current: 1mA; (5)SYNC Pin Current: 1mA; (6)Operating Junction Temperature Range:– 40 to 125℃; (7)Storage Temperature Range: – 65 to 150℃; (8)Lead Temperature (Soldering, 10 sec): 300℃.

Features

LT1961EMS8E#PBF features: (1)1.5A Switch in a Small MSOP Package; (2)Constant 1.25MHz Switching Frequency; (3)Wide Operating Voltage Range: 3V to 25V; (4)High Efficiency 0.2Ω Switch; (5)1.2V Feedback Reference Voltage; (6)±2% Overall Output Voltage Tolerance; (7)Uses Low Profile Surface Mount External Components; (8)Low Shutdown Current: 6μA; (9)Synchronizable from 1.5MHz to 2MHz; (10)Current-Mode Loop Control; (11)Constant Maximum Switch Current Rating at All Duty Cycles; (12)Thermally Enhanced Exposed Pad 8-Lead Plastic MSOP Package.
