Product Summary
The AD8628ARTZ is an amplifier. It has ultralow offset, drift, and bias current. The AD8628ARTZ is a wide bandwidth auto-zero amplifier featuring rail-to-rail input and output swings and low noise. Operation is fully specified from 2.7 V to 5 V single supply (±1.35 V to ±2.5 V dual supply). The applications of the AD8628ARTZ include Automotive sensors, Pressure and position sensors, Strain gage amplifiers, Medical instrumentation, Thermocouple amplifiers, Precision current sensing, Photodiode amplifier.
Parametrics
AD8628ARTZ absolute maximum ratings: (1)Supply Voltage: 6 V; (2)Input Voltage GND: -0.3 V to VS- + 0.3 V; (3)Differential Input Voltage: ±5.0 V; (4)Output Short-Circuit Duration to GND: Indefinite; (5)Storage Temperature Range: -65 to +150℃; (6)Operating Temperature Range: -40 to +125℃; (7)Junction Temperature Range: -65 to +150℃; (8)Lead Temperature Range (Soldering, 60 s): 300℃.
Features
AD8628ARTZ features: (1)Lowest auto-zero amplifier noise; (2)Low offset voltage: 1 μV; (3)Input offset drift: 0.002 μV/℃; (4)Rail-to-rail input and output swing; (5)5 V single-supply operation; (6)High gain, CMRR, and PSRR: 120 dB; (7)Very low input bias current: 100 pA max; (8)Low supply current: 1.0 mA; (9)Overload recovery time: 10 μs; (10)No external components required.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 AD8628ARTZ-R2 |
|
IC OPAMP CHOPPER R-R SOT23-5 |
Data Sheet |
Negotiable |
|
||||||||||||||||||
|
AD8628ARTZ-REEL7 |
|
IC OPAMP CHOPPER R-R SOT23-5 |
Data Sheet |
|
|
||||||||||||||||||
