AT24C04BN-SH-T

Two-wire Serial EEPROM, 4KBIT, 1MHZ, 8SOIC, 1.8 V, 5.0 mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~0.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~0.20

PartNumber:: AT24C04BN-SH-T

Brand:: ATMEL Corporation - ATMEL | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Joy's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-29

From Other Seller

Part Number:AT24C04BN-SH-T
US $0.10 - 0.20
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT24C04BN-SH-T is a Two-wire Serial EEPROM. It provides 4096bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 512/1024 words of 8 bits each. The AT24C04BN-SH-T is optimized for use in many industrial and commercial applications where low-power and low-voltage operation are essential. The AT24C04BN-SH-T is available in space-saving 8-lead PDIP, 8-lead JEDEC SOIC, 8-lead Ultra-Thin Mini-MAP (MLP 2x3), 5-lead SOT23, 8-lead TSSOP, and 8-ball dBGA2 packages and is accessed via a Two-wire serial interface. In addition, the AT24C04BN-SH-T is available in 1.8V (1.8V to 5.5V) version.

Parametrics

AT24C04BN-SH-T absolute maximum ratings: (1)Operating Temperature:-55℃ to +125℃; (2)Storage Temperature:-65℃ to + 150℃; (3)Voltage on Any Pin with Respect to Ground:-0.1V to +7.0V; (4)Maximum Operating Voltage:6.25V; (5)DC Output Current: 5.0 mA.

Features

AT24C04BN-SH-T features: (1)Low-voltage and Standard-voltage Operation: 1.8 (VCC = 1.8V to 5.5V) ; (2)Internally Organized 512 x 8 (4K), or 1024 x 8 (8K) ; (3)Two-wire Serial Interface ; (4)Schmitt Trigger, Filtered Inputs for Noise Suppression ; (5)Bidirectional Data Transfer Protocol ; (6)1 MHz (5V), 400 kHz (1.8V, 2.5V, 2.7V) Compatibility ; (7)Write Protect Pin for Hardware Data Protection ; (8)16-byte Page (4K, 8K) Write Modes ; (9)Partial Page Writes Allowed ; (10)Self-timed Write Cycle (5 ms max) ; (11)High-reliability: Endurance: 1 Million Write Cycles, Data Retention: 100 Years; (12)8-lead PDIP, 8-lead JEDEC SOIC, 8-lead Ultra-Thin Mini-MAP(MLP 2x3), 5-lead SOT23, 8-lead TSSOP and 8-ball dBGA2 Packages ; (13)Lead-free/Halogen-free; (14)Die Sales: Wafer Form and Tape and Reel.
